Multiverse connects you to a growing library of effects by a variety of independent developers. Access new sounds instantly via the Audio Shop and configure your pedalboards using the included Multiverse Designer software for desktop.
Each Developer Edition pedal comes with the Aviate Audio Effect Creator app, so you can develop and test your own digital effects.
The Multiverse pedal runs your custom effects chains & boasts a variety of routing options including stereo. Effect parameters can be assigned to any of the hardware controls (see tech specs for list of assignable hardware controls).
Audio developers are able to program and test their own effects on the Developer Edition pedal alongside all of the effects available in the Aviate Audio Multiverse library. Aviate Audio licensed developers can publish their own free and premium effects for Multiverse on the Aviate Audio Shop.
Support is available for developers and all Multiverse users. Product manuals and SDK are available on our downloads page. Contact us for support on the Aviate Audio Discord channel, or via our email: contactus@aviateaudio.com.
Beyond Black with matte finish & Developer Edition model logo.
1.3” OLED Display
Four programmable rotary encoders w/ switch
Two programmable stomp switches
Two assignable LEDs
MIDI input for control (support coming soon)
2x Expression inputs via TRS connector
Dedicated input Gain control and output Volume controls
Power can be provided either by the DC Power Input (5V to 9V) or the USB-C port
USB C port with programming interface and audio interface
Stereo 1/4" TRS audio Input & Output
Stereo CODEC, 48Khz
Cortex M7 @ 600 MHz
1 MByte RAM
8 MByte external SRAM
Power Supply Specification 9V output, center-negative polarity, 250 mA minimum current, 2.1mm ID, 5.5mm OD
